- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: DG54
chassis | Engine power | Driving | Max. running | |
VOLVO | 500HP(369KW) | 8 X 4 | ≥90km/h | |
item | parameter | |||
Rated working height | 54m | |||
platform load | 400 Kg | |||
Max. working radius | 18.5m | |||
Outrigger span | 6.95m/5.96m | |||
Boom action time | ≤200S | |||
Outrigger extending time | ≤40S | |||
Swing rate | 0 ～2r/min | |||
Pump | American import pump | |||
Pump flow | 6000 L/min | |||
Fire monitor | American import fire monitor, 100m wireless control | |||
Monitor reach | water ≥65m foam≥55m | |||
Tank | water(4T)foam(1t) | |||
dimension(mm) | 13000(L) x 2500(W) x 3980(H) | |||
- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: DG54
