- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: JP40
chassis | engine power | driving type | max. running speed | |
original Mercedes benz3341 | 410HP | 6 X 4 | ≥104km/h | |
BEIBEN benz2534 | 336HP | 6 X 4 | ≥90km/h | |
item | parameter | |||
rated working height | 40m | |||
max.working radius | 18m | |||
outrigger span(horizontal/horizontal) | 5.4m/5.2m | |||
boom opening time | ≤110S | |||
outrigger extending time | ≤30S | |||
rotation rate | 0～2r/min | |||
fire pump | american import fire pump | |||
fire pump flow | 5400 L/min | |||
fire monitor | american import monitor(100m wireless control) | |||
fire monitor reach | water≥75m foam≥65m | |||
tank | water（4T）foam（2T） | |||
dimension(mm) | 11200(L) x 2500(W) x 3900(H) | |||
- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: JP40
