- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: JP56
| chassis | engine power | driving type | max. running speed | |
Sweden VOLVO | 480HP/400HP | 8 X 4 | ≥94km/h | |
item | parameter | |||
rated working height | 56m | |||
max.working radius | 23m | |||
outrigger span(horizontal/horizontal) | 6.8m/5.5m | |||
boom opening time | ≤120S | |||
outrigger extending time | ≤30S | |||
rotation rate | 0～2r/min | |||
fire pump | american import fire pump | |||
fire pump flow | 10200 L/min；5400 L/min | |||
fire monitor | american import monitor(100m wireless control) | |||
fire monitor reach | water≥75m foam≥65m | |||
tank | water（4.1T）foam（1.2T） | |||
dimension(mm) | 13300(L) x 2500(W) x 3990(H) | |||
- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: JP56
