- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: YT18
| chassis | engine power | driving type | max. running speed | |
China FAW | 350HP | 4 X 2 | 110km/h | |
item | parameter | |||
rated working height | 18m | |||
max.working radius | 16m | |||
outrigger span(horizontal/horizontal) | 4.5m/5.2m | |||
boom opening time | ≤60S | |||
outrigger extending time | ≤30S | |||
rotation rate | 0～2r/min | |||
fire monitor | american import monitor(100m wireless control) | |||
fire monitor reach | water≥75m foam≥65m | |||
Hydraulic winch | H10000 | |||
winch pulling force | 4600kg | |||
winch control mode | Wire control | |||
lighting system | SG75-4400F | |||
lighting control mode | Wire control/wireless control | |||
lighting power | 400W X 4 | |||
max. Lifting height | 7.5m | |||
light rotation angle | 380° | |||
light up and down angle | 330° | |||
dimension(mm) | 10000(L) x 2500(W) x 3800(H) | |||
