- Guaranteed Secure Payments on Every Order
- Refund if your item is not delivered or as described
- Buyer Protection after order confirmation
- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: YT32
chassis | engine power | driving type | max. running speed | |
SwedenvolvoVOLVO | 280HP | 4 X 2 | ≥99km/h | |
SINOTRUCK HOWO | 290HP | 4 X 2 | ≥90km/h | |
item | parameter | |||
rated working height | 32m | |||
platform load | 360 Kg | |||
max.working radius | 18m | |||
outrigger span(horizontal/horizontal) | 5.5m/5.9m | |||
boom opening time | ≤90S | |||
outrigger extending time | ≤30S | |||
rotation rate | 0～2r/min | |||
fire monitor | american import monitor(100m wireless control) | |||
fire monitor reach | water≥75m foam≥65m | |||
dimension(mm)volvo | 10500(L) x 2500(W) x 3750(H) | |||
dimension(mm)HOWO | 10000(L) x 2500(W) x 3850(H) | |||
- Size: 10180 x 2500x 3650
- Place of Origin: China
- Brand Name: jietong
- Model Number: YT32
